Our free-standing lithium-ion battery systems have become popular due to their high efficiency, compact size, their low weight, and their scalability. Lower voltage modules (48 V) are designed for applications in the living area and network-independent installations. High-voltage modules are very flexible in design and popular with our customers.
It has several functions, including remote monitoring, software upgrades, modular design, simple furnishings, and one of the most cost-effective options for storing solar energy.
10 kWh capacity is very popular and you can choose more capacity from our scalable and flexible high-voltage module battery systems.
Characteristics:
• RS485/CAN
• Installation: free-standing on the floor
• tailored to different global top inverter stamps
• High-security standard of the LFP (LIFEP04) cell
• Long-lived battery design supported by efficient compensation technology
• Extended BMS protection functions
| Model | BESS-P10 |
|---|---|
| Battery type | Lifepo4 |
| energy | 10240Wh |
| capacity | 200Ah |
| Design voltage | 51.2V |
| Working voltage area | 40-58.4V |
| Max. Charging current | 100a |
| Max. Discharge current | 100a |
| Standard charging current | 100a |
| Standard entertainment current | 200a |
| Dod | 100% |
| Max. Parallel quantity | 6 |
| Designed lifespan | 6000 cycles |
| operating temperatur | Charge 0-60 discharge -10-60 |
| Moisture | 5-95% |
| Nominal operating height | ＜ 3000 m |
| IP rating | IP65 |
| Installation method | Wall bracket/shelf |
| communication | RS485/CAN/RS232 |
| Certification | MSDS UN38.3 |
| Net weight | 90.6kg |
| Dimensions (L*B*H) | 502*171*823 mm |
