The all-in-one system is great because it is easy to use and effortlessly installed.
It is equipped with an LFP-safe battery cell that supports continuous discharge with a high rate and a long service life.
It is characterized by efficiency, low weight, and compatibility. The all-in-one system is designed for residential applications and network-independent installations with compact dimensions.
Characteristics:
Built-in MPPT solar loader or inverter
Configurable battery charging current based on applications via LCD setting
Configurable priority for alternating current/solar loader via LCD setting
Compatible with mains voltage or generator power
Automatic restart while AC recovered
Overload/over temperature/short circuit protection
Intelligent battery charger design for optimized battery power
Cold start function
Zero transmission time
| Model | BESS-BRE-UPS |
|---|---|
| Rated Capacity | 5000VA/5000W |
| capacity | 4.8kWh |
| Current Voltage | 230vac |
| Tension | 110--280VAC |
| AC Voltage Control | 230VAC (5%) |
| Issue THDV | <3 % in linear stress, <8 % in the event of non -linear stress |
| Overvoltage Protection | 10,000 VA for 5 seconds |
| Efficiency Tip | 93 % in line mode, 90 % in battery mode |
| Current Voltage | 48vdc |
| Tension | 42-54.8V |
| Cell Type | LFP |
| Protection | Overflow, overvoltage, Short circuit, undervoltage overtemp |
| Max. Permanent Charging Current | 60a |
| Max Permanent Charging Current | 100a |
| Charge the temperatures | 0 ~ 55 ° C |
| Unloading temperature | -20 ~ 60 ° C |
| Max PV Array Leader Voltage | 145vdc |
| Max PV Array Performance | 4000 W |
| MPP AREA for Operating Voltage | 60-115VDC |
| Max Solarladestrom | 80a |
| Max AC Charging Current | 60a |
| Max. Charging Current | 140a |
| Dimensions | 380x380x750mm |
| Net Weight | 75kg |
| IP Protection | IP21 |
| installation | floor |
| Guarantee, service life | 5 years, 10 years |
